【Voltage Compatibility】
When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction.
【Plug Type】
Our products use Japanese plug types (A or B type).
Please use a conversion adapter if necessary.
【Important Note on Transformers and Adapters】
A transformer adjusts voltage to match your device’s requirements.
A conversion adapter only changes the plug shape and does not adjust voltage.
Using only a conversion adapter without a transformer may result in damage to the product.
【Liability】
We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer.
Kindly confirm these details before placing your order.
----------------------------------------------------------------------
4K Ultra HD Video Quality: The 4K HDMI USB camera adopts a 1/2.8-inch IMX415 color CMOS image sensor, delivering superior noise reduction, color reproduction, and low image latency at 4K resolution. Approximately 8 seconds after opening the preview software
Simultaneous USB and HDMI output: USB Type-C power supply, simultaneous output of Type-C and HDMI display. The HDMI output connects to an HDMI monitor to capture on-screen video shows for education, or to an HDMI video capture card for live streaming of small-scale activities.
5-50mm 10X Manual Zoom Lens: The 4K 5-50mm varifocal USB camera is great, with excellent range and depth of field 5-50mm, allowing you to get very close to some objects, almost macro. With manual focus, you can control zoom in and out, adjust focus and aperture size to brighten your subjects, and use the lens screw to lock them in place.
Video format: Improves compression efficiency, lowers bandwidth requirements, and improves video quality. H.264/MJPEG/YUY2 is optional and can drive 3840x2160 MJPEG 30fps/ H.264 30fps. Capture ultra-high resolution live images up to 3840x2160 30fps, Full HD video 1080p 30fps for high quality live streaming, video calling on Windows / Mac-OS / Linux / Android.
Wide application: Compatible with UVC free drivers, webcams with wide compatibility with third-party software and operating systems, and instant messaging applications such as Skype, MSN, Facebook, and live streaming. Compatible with multiple OS including Windows, Linux, and Mac-OS.
specification:
Model: ELP-USB4KCAM01H-CFV(5-50)-J
Sensor: 1/2.8 inch IMX415
Maximum resolution: 3840(H)X2160(V)
Sensitivity: 0.65V/lux second @550nm
Pixel size: 1.45μmx1.45μm
Video compression: MJPEG/YUY2(YUYV)/H.264/
Resolution and frame rate:
3840x2160 MJPEG 30fps/ H.264 30fps/ 30fps
2560x1440 MJPEG 30fps/ H.264 30fps/
1920x1080 MJPEG 30fps/ H.264 30fps/ YUY2 5fps
1280x720 MJPEG 30fps/ H.264 30fps/ YUY2 10fps
1024x576 MJPEG 30fps/ H.264 30fps/ YUY2 15fps
960x540 MJPEG 30fps/ H.264 30fps/ YUY2 15fps
640x480 MJPEG 30fps/ H.264 30fps/ YUY2 30fps
640x360 MJPEG 30fps/ H.264 30fps/ YUY2 30fps
Center definition: 1000LW/PH(center)
S/N ratio: 30dB
Minimum illuminance: 0.2Lux
Shutter type: electronic rolling shutter/frame exposure
Connection port type: USB 2.0 interface &HDMI v1.4 interface
AEC: Support, AWB: Support, AGC: Support
Adjustable parameters:
Brightness, contrast, saturation, hue, sharpness, gamma, white balance, backlight compensation, exposure
Lens parameters: 180 degree fisheye lens
Power and Interface: USB Type-C power supply, connect Type-C and HDMI display at the same time
Working voltage: DC5V
Working current: 480-500mA
Dimensions: double deck, 38mm x 38mm
Storage temperature: -20℃~85℃
Operating temperature: -10°C to 70°C
USB cable: 2 cables
(1 x 1.2m cable with Type-C port, 1 x 1.5m cable with HDMI port)
Operating system requests: Win7/Win8/Win9/Win10/Win11 etc.
LinuxwithUVC MAC-OSX10.4.8 or later, Android5.x or later
